LAPP Industrial Tray Cable Solutions

LAPP Industrial Tray Solutions

LAPP tray cables have a well-earned reputation for playing critical roles in a wide array of industries and manufacturing applications. Lapp Tannehill's business partners depend on the quality, performance, and durability of LAPP tray cables to help keep their power, control, communications, and data lines at optimal performance, even in the most demanding conditions.

LAPP tray cables offer many valuable benefits for manufacturers and electrical engineers:

  • Oil-resistant, temperature-resistant, and UV-resistant
  • Superior bending radius
  • No conduit required
  • Direct burial capabilities
  • UL TC-ER approved

Tray Cables with Unrivaled Flexibility, Durability, and Cost-Effectiveness

For the most effective and long-lasting performance, it’s critical to know your installation environment for all types and voltages of tray cable, including where the cables are going to be run and important environmental factors such as cold, hot, damp, oil-heavy, or washdown conditions.

The applications are equally important, including significant curves, rises and falls, trays being run next to conveyors, and torsion ratings for wind turbines. Cold temperature flexibility ratings are also significant and can vary from -5˚C (23˚F) to -25˚C (-13˚F). Installations below the cold temperature flexibility can potentially cause the cable to be damaged during installation.

LAPP’s 600V power and control tray cables come in a wide variety of insulation and jacket materials. These cables pass stringent impact and crush tests per UL 1569 and don’t require conduits, which lowers operational and maintenance costs and increases layout flexibility. A smooth, round jacket design optimizes the seal when used with cable glands and connectors.

LAPP also offers data and communication cable that can be run in cable trays. Most are PLTC (power limited tray cable) rating per UL 13 and are PLTC-ER (exposed run) rated. PLTC cables can be run in the same tray as 600V power and control tray cables when they are separated by a divider.

Partner with the Tray Cable Industry Leader

When you buy your tray cables from Lapp Tannehill you are not only selecting reliable products but high-quality customer service as well. We offer an extensive line of value-added services to complete your purchase.

Lapp Tannehill offers the following industrial tray cable solutions:

View our table below to easily compare the various LAPP products and help you make the best decision for your application. And to find out more about LAPP tray cable solutions, please contact us at Lapp Tannehill with any questions.

Product Description Application Advantages
ÖLFLEX® TRAY II & ÖLFLEX® CONTROL TM ÖLFLEX® TRAY II & ÖLFLEX® CONTROL TM offer unrivaled reliability, flexibility, and durability for machine tool applications.
  • UL TC-ER & CSA CIC/TC
  • Meets UL Oil Res I & II and AWM 21098
  • UL MTW
  • WTTC per UL 2277
  • Higher abrasion resistance
  • Superior flexibility down to -25°C (-13˚F)
  • -40°C (-40˚F) cold bend
  • Oil and chemical resistant
ÖLFLEX® TRAY VTC ÖLFLEX® TRAY VTC offers greater flexibility and oil resistance when compared to commodity tray cables. Ideal for new plant installations and factory expansions.
  • Easier to pull than standard tray cable
  • UL TC-ER approval reduces material costs
  • UL wet rating +90°C (194˚F)
  • Black numbered conductors with printed color code for easy identification
  • UV resistant and direct burial
ÖLFLEX® AUTO-I ÖLFLEX® AUTO-I offers durability and reliability for heavy-duty tray applications as well as in machine wiring.
  • UL TC-ER & CSA CIC/TC approval
  • UV resistant
  • Number coded for easy wiring with either blue, red, orange, black, or yellow conductors
  • TPE jacket
ÖLFLEX® I 304 ÖLFLEX® I 304 instrumentation cable offers flexibility and durability in industrial applications. Rated for UL CMG, PLTC & ITC and CSA CMG.
  • UL/CSA rated 300V
  • Passes UL & CSA Flame Test (70,000 BTU)
  • Sunlight & UV resistant, direct burial
  • Rated +105°C (221˚F)
UNITRONIC® 300/300S UNITRONIC® 300 offers flexibility and durability that are expected for internal and external wiring of OEM equipment and routing through cable tray.
  • UL PLTC-ER
  • Extended temperature rating of -40° C (-40˚F) to +105°C (221˚F)
  • Flexible design for ease of routing
  • Suitable for use in cable tray
  • Oil- and UV-resistant jacket
  • Sequential foot markings for ease of installation
  • Maximum RFI & EMI protection
UNITRONIC® 300 STP UNITRONIC® 300 STP is your cable of choice for internal and external wiring of OEM equipment. Twisted and shielded pairs, unrivaled oil resistance, and improved flexibility make it ideal for tray applications.
  • UL PLTC-ER
  • Oil- and UV-resistant jacket (Oil Res I)
  • Extended temperature rating of -40°C (-40˚F) to +105°C (221˚F)
  • Flexible design for ease of routing
  • Suitable for use in cable tray
  • Sequential foot markings for ease of installation
ETHERLINE® TRAY ETHERLINE® TRAY is designed for flexible and tray applications. Engineered to protect against EMI and ideal for use in areas where reliable transmission is key.
  • Wide application range due to multiple certifications
  • UL PLTC (power limited tray cable) for protected use on cable trays
  • UL Oil Res I
  • Suitable for EtherNet/IP applications
ETHERLINE® CAT.5 ETHERLINE® CAT.5 provides reliable network communication in demanding industrial applications while ensuring protection from EMI. Suitable for stationary tray applications.
  • UL PLTC
  • Double screening ensures high transmission reliability in areas with EMI
  • Flame retardant
  • Highly oil- and abrasion-resistant PUR jacket
  • Conforms to PROFINET® Standard
  • Fast connect style allows for quick installation
