Power and Control Cable

Power and control cables are the most common electrical cables used in residential, commercial, and industrial applications for power supply and signal transmission.

What is a power cable? A power cable is an assembly of one or more electrical conductors that transfer energy from its source – it’s usually the primary cable used to make its operating equipment work.

What is a control cable? Control cables are single or multiconductor cables that transfer data to other devices for measurement, regulation, and automation control.

Power and control cables are driven by application demands varying in levels of voltage, shielding options, flexibility requirements, oil resistance, and types of insulation to withstand environmental and operating conditions.

Close up of a power control cable with the shielding, conductors, and wires exposed.Close up of a power control cable with the shielding, conductors, and wires exposed.

LAPP Tannehill maintains an extensive inventory of gauge sizes, stranding, insulation, and colors of power and control cable. The following table provides a few recommended types of power and control cable by general application. You can also browse our products below or contact us for additional assistance.

Application Type Suggested Power & Control Cable
Flexible Power & Control Cable Alpha EcoFlex, LAPP ÖLFLEX®190
Continuous Flex Power & Control Cable Alpha Industrial Series F, LAPP ÖLFLEX® FD 855 P
VFD Cable LAPP ÖLFLEX® VFD
Tray Rated Cable LAPP ÖLFLEX® TRAY II
Stationary Power & Control Cable Alpha Series M, LAPP ÖLFLEX® 490 P, LAPP ÖLFLEX® CLASSIC 100

Request a sample! If you aren't sure which type of power and control cable you need, you can request a sample. Fill out our form and a representative will reach out to get additional details.

ÖLFLEX® 190, ÖLFLEX® CONTROL TM, EcoFlex, & more

Flexible Power & Control Cable

Flexible Power & Control CableFlexible power and control cables feature specially formulated jackets which allow for easier installation and an increased bend radius. Available in shielded and unshielded options, these cables can be applied in many different applications such as VFD drive/motor connections, HVAC, conveyors, automated manufacturing systems, cable tracks, continuous flex applications, along with many others.

Lapp Tannehill maintains an extensive inventory of gauge sizes, stranding, insulation, and colors of flexible control cable. Browse our products below or contact us if you have any questions.

ÖLFLEX® 190, ÖLFLEX® CONTROL TM, EcoFlex, & more

Items 331-340 of 2261

Set Ascending Direction
  1. 251611XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 11 Conductor - Black Jacket - Orange Conductors
    251611XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 11 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251611XO
    Mfg #: 251611XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.569

    NOMINAL OD (MM): 14.5

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  2. 251612XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 12 Conductor - Black Jacket - Orange Conductors
    251612XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 12 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251612XO
    Mfg #: 251612XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.569

    NOMINAL OD (MM): 14.5

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  3. 251619XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 19 Conductor - Black Jacket - Orange Conductors
    251619XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 19 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251619XO
    Mfg #: 251619XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.698

    NOMINAL OD (MM): 17.7

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  4. 251625XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 25 Conductor - Black Jacket - Orange Conductors
    251625XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 25 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251625XO
    Mfg #: 251625XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.798

    NOMINAL OD (MM): 20.3

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  5. 251633XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 33 Conductor - Black Jacket - Orange Conductors
    251633XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 33 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251633XO
    Mfg #: 251633XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.877

    NOMINAL OD (MM): 22.3

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  6. 251642XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 42 Conductor - Black Jacket - Orange Conductors
    251642XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 42 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251642XO
    Mfg #: 251642XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.977

    NOMINAL OD (MM): 24.8

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  7. 251649XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 49 Conductor - Black Jacket - Orange Conductors
    251649XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 49 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251649XO
    Mfg #: 251649XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 1.043

    NOMINAL OD (MM): 26.5

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  8. 251665XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 65 Conductor - Black Jacket - Orange Conductors
    251665XO - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 16 AWG 65 Conductor - Black Jacket - Orange Conductors

    Part #: OLF251665XO
    Mfg #: 251665XO
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 1.191

    NOMINAL OD (MM): 30.3

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  9. 251803XY - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 18 AWG 3 Conductor - Black Jacket - Yellow Conductors
    251803XY - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 18 AWG 3 Conductor - Black Jacket - Yellow Conductors

    Part #: OLF251803XY
    Mfg #: 251803XY
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.309

    NOMINAL OD (MM): 7.8

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
  10. 251805XY - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 18 AWG 5 Conductor - Black Jacket - Yellow Conductors
    251805XY - LAPP ÖLFLEX® FD AUTO-X Unshielded Multiconductor Cable - 18 AWG 5 Conductor - Black Jacket - Yellow Conductors

    Part #: OLF251805XY
    Mfg #: 251805XY
    Manufacturer: LAPP

    Heavy duty continuous flex control cable

    SERIES: ÖLFLEX® FD AUTO-X

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: Thermoplastic Elastomer (TPE)

    NOMINAL OD (IN): 0.358

    NOMINAL OD (MM): 9.1

    VOLTAGE: 600V

    TRAY RATINGS: UL TC-ER

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved, UL WTTC

    Learn More
    Request Quote for Price

    Contact 800-633-6339 for Availability
    FT

    Add to Compare
