ÖLFLEX® Flexible Power & Control Cables


ÖLFLEX® Flexible Power & Control Cables
Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs.
Request a Sample
If you'd like to try a sample ÖLFLEX®, complete the form found at the button below. A representative will reach out to you with some questions on your application before sending you the best product for your needs.
PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.
Properties
- Flexible, almost entirely oil-resistant and universally applicable
- Fulfills the most demanding requirements for electrical and mechanical properties
- Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
- Suitable for fixed connection or energy supply chains
- Available in Halogen-free options and with international licenses
Fields of Application
- Mechanical, tool, system, and apparatus engineering
- Measurement, control, heating, and climate technology
- Wind-powered and photovoltaic plants
- Public buildings, airports, and stations
- Medical technology
- Chemical industry, composting plants, and sewage works
- Food and drink industry
- Construction machinery, automotive, and agricultural equipment
- Robotics
- Stage engineering
- Mobile electrical equipment (electrical instruments, power tools, household goods)
- Many more
Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.

ÖLFLEX® Flexible Power & Control Cables
Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs. If you'd like to speak with one of our representatives for assistance, please contact us below.
PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.
Properties
- Flexible, almost entirely oil-resistant and universally applicable
- Fulfills the most demanding requirements for electrical and mechanical properties
- Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
- Suitable for fixed connection or energy supply chains
- Available in Halogen-free options and with international licenses
Fields of Application
- Mechanical, tool, system, and apparatus engineering
- Measurement, control, heating, and climate technology
- Wind-powered and photovoltaic plants
- Public buildings, airports, and stations
- Medical technology
- Chemical industry, composting plants, and sewage works
- Food and drink industry
- Construction machinery, automotive, and agricultural equipment
- Robotics
- Stage engineering
- Mobile electrical equipment (electrical instruments, power tools, household goods)
- Many more
Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.
-
1119065 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 20 AWG 65 Conductors - GrayPart #: OLF1119065
Mfg #: 1119065
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.772
NOMINAL OD (MM): 19.6
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119080 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 20 AWG 80 Conductors - GrayPart #: OLF1119080
Mfg #: 1119080
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.831
NOMINAL OD (MM): 21.1
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119100 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 20 AWG 100 Conductors - GrayPart #: OLF1119100
Mfg #: 1119100
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.929
NOMINAL OD (MM): 23.6
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119852 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 2 Conductors - GrayPart #: OLF1119852
Mfg #: 1119852
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.224
NOMINAL OD (MM): 5.7
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119203 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 3 Conductors - GrayPart #: OLF1119203
Mfg #: 1119203
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.236
NOMINAL OD (MM): 6
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119204 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 4 Conductors - GrayPart #: OLF1119204
Mfg #: 1119204
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.256
NOMINAL OD (MM): 6.5
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119205 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 5 Conductors - GrayPart #: OLF1119205
Mfg #: 1119205
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.28
NOMINAL OD (MM): 7.1
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119207 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 7 Conductors - GrayPart #: OLF1119207
Mfg #: 1119207
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.315
NOMINAL OD (MM): 8
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119212 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 12 Conductors - GrayPart #: OLF1119212
Mfg #: 1119212
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.413
NOMINAL OD (MM): 10.5
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
1119218 - LAPP ÖLFLEX® CLASSIC 110 Flexible Power and Control Cable - Unshielded - 18 AWG 18 Conductors - GrayPart #: OLF1119218
Mfg #: 1119218
Manufacturer: LAPPFlexible number-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 110
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Unshielded
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.5
NOMINAL OD (MM): 12.7
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
