ÖLFLEX® Flexible Power & Control Cables


ÖLFLEX® Flexible Power & Control Cables
Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs.
Request a Sample
If you'd like to try a sample ÖLFLEX®, complete the form found at the button below. A representative will reach out to you with some questions on your application before sending you the best product for your needs.
PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.
Properties
- Flexible, almost entirely oil-resistant and universally applicable
- Fulfills the most demanding requirements for electrical and mechanical properties
- Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
- Suitable for fixed connection or energy supply chains
- Available in Halogen-free options and with international licenses
Fields of Application
- Mechanical, tool, system, and apparatus engineering
- Measurement, control, heating, and climate technology
- Wind-powered and photovoltaic plants
- Public buildings, airports, and stations
- Medical technology
- Chemical industry, composting plants, and sewage works
- Food and drink industry
- Construction machinery, automotive, and agricultural equipment
- Robotics
- Stage engineering
- Mobile electrical equipment (electrical instruments, power tools, household goods)
- Many more
Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.

ÖLFLEX® Flexible Power & Control Cables
Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs. If you'd like to speak with one of our representatives for assistance, please contact us below.
PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.
Properties
- Flexible, almost entirely oil-resistant and universally applicable
- Fulfills the most demanding requirements for electrical and mechanical properties
- Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
- Suitable for fixed connection or energy supply chains
- Available in Halogen-free options and with international licenses
Fields of Application
- Mechanical, tool, system, and apparatus engineering
- Measurement, control, heating, and climate technology
- Wind-powered and photovoltaic plants
- Public buildings, airports, and stations
- Medical technology
- Chemical industry, composting plants, and sewage works
- Food and drink industry
- Construction machinery, automotive, and agricultural equipment
- Robotics
- Stage engineering
- Mobile electrical equipment (electrical instruments, power tools, household goods)
- Many more
Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 18 AWG 2 Conductors - TransparentPart #: OLF0035220
Mfg #: 0035220
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.311
NOMINAL OD (MM): 7.9
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 18 AWG 3 Conductors - TransparentPart #: OLF0035221
Mfg #: 0035221
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.323
NOMINAL OD (MM): 8.2
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 18 AWG 4 Conductors - TransparentPart #: OLF00352223
Mfg #: 00352223
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.343
NOMINAL OD (MM): 8.7
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 18 AWG 5 Conductors - TransparentPart #: OLF00352233
Mfg #: 00352233
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.374
NOMINAL OD (MM): 9.5
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 16 AWG 2 Conductors - TransparentPart #: OLF0035000
Mfg #: 0035000
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.39
NOMINAL OD (MM): 9.9
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 16 AWG 3 Conductors - TransparentPart #: OLF0035458
Mfg #: 0035458
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.406
NOMINAL OD (MM): 10.3
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 16 AWG 4 Conductors - TransparentPart #: OLF00354593
Mfg #: 00354593
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.445
NOMINAL OD (MM): 11.3
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 16 AWG 5 Conductors - TransparentPart #: OLF00354603
Mfg #: 00354603
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.496
NOMINAL OD (MM): 12.6
VOLTAGE: 500V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 14 AWG 3 Conductors - TransparentPart #: OLF0035011
Mfg #: 0035011
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.465
NOMINAL OD (MM): 11.8
VOLTAGE: 750V
STANDARDS/APPROVALS: CE Approved
-
LAPP ÖLFLEX® CLASSIC 100 CY Flexible Power and Control Cable - Tinned copper braid - 14 AWG 4 Conductors - TransparentPart #: OLF00350173
Mfg #: 00350173
Manufacturer: LAPPFlexible color-coded power & control cable
SERIES: ÖLFLEX® CLASSIC 100 CY
CONDUCTOR MATERIAL: Bare Copper
CONDUCTOR STRANDING: Stranded
SHIELDING: Tinned copper braid
JACKET MATERIAL: PVC
NOMINAL OD (IN): 0.531
NOMINAL OD (MM): 13.5
VOLTAGE: 750V
STANDARDS/APPROVALS: CE Approved
