ÖLFLEX® Flexible Power & Control Cables

Different OLFLEX products, such as Servo FD and Heat 125, with the LAPP and OLFLEX logos.Different OLFLEX products, such as Servo FD and Heat 125, with the LAPP and OLFLEX logos.

ÖLFLEX® Flexible Power & Control Cables

Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs.

Request a Sample

If you'd like to try a sample ÖLFLEX®, complete the form found at the button below. A representative will reach out to you with some questions on your application before sending you the best product for your needs.

Request a Sample


PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.

Try our Cross-Reference & Product Selection Tool

Properties

  • Flexible, almost entirely oil-resistant and universally applicable
  • Fulfills the most demanding requirements for electrical and mechanical properties
  • Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
  • Suitable for fixed connection or energy supply chains
  • Available in Halogen-free options and with international licenses

Fields of Application

  • Mechanical, tool, system, and apparatus engineering
  • Measurement, control, heating, and climate technology
  • Wind-powered and photovoltaic plants
  • Public buildings, airports, and stations
  • Medical technology
  • Chemical industry, composting plants, and sewage works
  • Food and drink industry
  • Construction machinery, automotive, and agricultural equipment
  • Robotics
  • Stage engineering
  • Mobile electrical equipment (electrical instruments, power tools, household goods)
  • Many more

Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.

ÖLFLEX® 190, Tray II, VFD SLIM, Power IX, & more

OLFLEX Flexible Power & Control Cables

ÖLFLEX® Flexible Power & Control Cables

Introduced in 1959, ÖLFLEX® was the first control cable designed with color-coded wire. Today, LAPP’s ÖLFLEX® cables are some of the most widely used in the world. Our flexible and oil-resistant cables satisfy the highest demands and can withstand even the very toughest conditions. Turn to Lapp Tannehill for all of your ÖLFLEX® needs. If you'd like to speak with one of our representatives for assistance, please contact us below.

Contact Us button

PLEASE NOTE: LAPP PRODUCTS ARE NOT SUITABLE FOR THE INSIDE OF AIRPLANES AND HELICOPTERS, INCLUDING DRONES OR OTHER DIRECT AIR AND SPACE TRAVEL APPLICATIONS.

Properties

  • Flexible, almost entirely oil-resistant and universally applicable
  • Fulfills the most demanding requirements for electrical and mechanical properties
  • Comprehensive range for all environmental conditions, including wet/dry, EMC, indoor/outdoor, extreme temperature ranges, etc.
  • Suitable for fixed connection or energy supply chains
  • Available in Halogen-free options and with international licenses

Fields of Application

  • Mechanical, tool, system, and apparatus engineering
  • Measurement, control, heating, and climate technology
  • Wind-powered and photovoltaic plants
  • Public buildings, airports, and stations
  • Medical technology
  • Chemical industry, composting plants, and sewage works
  • Food and drink industry
  • Construction machinery, automotive, and agricultural equipment
  • Robotics
  • Stage engineering
  • Mobile electrical equipment (electrical instruments, power tools, household goods)
  • Many more

Browse the ÖLFLEX® cables below or download a pdf of the complete ÖLFLEX® catalog.

ÖLFLEX® 190, Tray II, VFD SLIM, Power IX, & more

Items 1371-1380 of 2719

Set Ascending Direction
  1. 8914044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 4 Conductor - Black
    OBSOLETE - 8914044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 4 Conductor - Black

    Part #: OLF8914044S
    Mfg #: 8914044S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.551

    NOMINAL OD (MM): 14

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  2. 8914074S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 7 Conductor - Black
    OBSOLETE - 8914074S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 7 Conductor - Black

    Part #: OLF8914074S
    Mfg #: 8914074S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.709

    NOMINAL OD (MM): 18

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  3. 8914184S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 18 Conductor - Black
    OBSOLETE - 8914184S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 14 AWG 18 Conductor - Black

    Part #: OLF8914184S
    Mfg #: 8914184S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 1.012

    NOMINAL OD (MM): 25.7

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  4. 8912044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 12 AWG 4 Conductor - Black
    OBSOLETE - 8912044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 12 AWG 4 Conductor - Black

    Part #: OLF8912044S
    Mfg #: 8912044S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.65

    NOMINAL OD (MM): 16.5

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  5. 8912074S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 12 AWG 7 Conductor - Black
    OBSOLETE - 8912074S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 12 AWG 7 Conductor - Black

    Part #: OLF8912074S
    Mfg #: 8912074S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.858

    NOMINAL OD (MM): 21.8

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  6. 8910044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 10 AWG 4 Conductor - Black
    OBSOLETE - 8910044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 10 AWG 4 Conductor - Black

    Part #: OLF8910044S
    Mfg #: 8910044S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.752

    NOMINAL OD (MM): 19.1

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  7. 8908044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 8 AWG 4 Conductor - Black
    OBSOLETE - 8908044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 8 AWG 4 Conductor - Black

    Part #: OLF8908044S
    Mfg #: 8908044S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.882

    NOMINAL OD (MM): 22.4

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  8. 8906044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 6 AWG 4 Conductor - Black
    OBSOLETE - 8906044S - LAPP ÖLFLEX® FD 890 CY Shielded Multiconductor Cable - 6 AWG 4 Conductor - Black

    Part #: OLF8906044S
    Mfg #: 8906044S
    Manufacturer: LAPP

    Super flexible heavy duty continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® FD 890 CY

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Tinned copper braid

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 1.066

    NOMINAL OD (MM): 27.1

    VOLTAGE: 600V

    STANDARDS/APPROVALS: UL Approved, CSA Approved, CE Approved

    Request Quote for Price

    Contact 800-633-6339 for Availability

  9. 1026700 - LAPP ÖLFLEX® CHAIN 809 Unshielded Multiconductor Cable - 20 AWG 2 Conductor - Gray
    1026700 - LAPP ÖLFLEX® CHAIN 809 Unshielded Multiconductor Cable - 20 AWG 2 Conductor - Gray

    Part #: OLF1026700
    Mfg #: 1026700
    Manufacturer: LAPP

    Continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® CHAIN 809

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.205

    NOMINAL OD (MM): 5.2

    VOLTAGE: 1000V

    STANDARDS/APPROVALS: CE Approved

    $559.09 / 1,000 FT$0.56 / 1 FT

    Contact 800-633-6339 for Availability


  10. 1026701 - LAPP ÖLFLEX® CHAIN 809 Unshielded Multiconductor Cable - 20 AWG 3 Conductor - Gray
    1026701 - LAPP ÖLFLEX® CHAIN 809 Unshielded Multiconductor Cable - 20 AWG 3 Conductor - Gray

    Part #: OLF1026701
    Mfg #: 1026701
    Manufacturer: LAPP

    Continuous flex control cable with PVC jacket

    SERIES: ÖLFLEX® CHAIN 809

    CONDUCTOR MATERIAL: Bare Copper

    CONDUCTOR STRANDING: Stranded

    SHIELDING: Unshielded

    JACKET MATERIAL: PVC

    NOMINAL OD (IN): 0.217

    NOMINAL OD (MM): 5.5

    VOLTAGE: 1000V

    STANDARDS/APPROVALS: CE Approved

    $755.88 / 1,000 FT$0.76 / 1 FT

    Contact 800-633-6339 for Availability
