TE Raychem RW-175 3/64 inch Single Wall Heat Shrink Tubing - Clear
TE Raychem RW-175 3/64 inch Single Wall Heat Shrink Tubing - Clear
Part #: RAYRW-175-3/64-X
Mfg #: RW-175-3/64-X
Manufacturer: TE Connectivity
Mfg #: RW-175-3/64-X
Manufacturer: TE Connectivity
Contact 800-633-6339 for Availability
TE Connectivity's RW-175 3/64 inch PVDF heat shrink tubing is a highly flame-resistant, high temperature, chemical resistant tubing. Color = Clear. TE RW-175-3/64-X.
Available to buy in increments of 100.
Specifications
Download Spec Sheet| MANUFACTURER TE Connectivity | MANUFACTURER PART NUMBER RW-175-3/64-X | AVAILABILITY Contact 800-633-6339 for Availability |
| SERIES RW-175 | HEAT SHRINK Yes | SHRINK RATIO 2:1 |
| WALL TYPE Single | MATERIAL PVDF | SIZE 3/64 |
| COLOR Clear | EXPANDED ID (IN) 0.046 | EXPANDED ID (MM) 1.17 |
| RECOVERED ID MAX (IN) 0.023 | RECOVERED ID MAX (MM) 0.58 | NOMINAL RECOVERED WALL THICKNESS (IN) 0.01 |
| NOMINAL RECOVERED WALL THICKNESS (MM) 0.25 | OPERATING TEMPERATURE -67°F to 347°F (-55°C to 175°C) | RECOVERY TEMPERATURE 347°F (175°C) |
| FLAMMABILITY Flame-Resistant | STANDARDS/APPROVALS UL Approved CSA Approved | MIL-SPEC AS23053/8 Full Spools Only |
| TRADE OR BRAND NAME RAYCHEM |
