TE Raychem MT5000 3/16 inch Medical Heat Shrink Tubing - Blue
TE Raychem MT5000 3/16 inch Medical Heat Shrink Tubing - Blue
Part #: RAYMT5000-3/16-6
Mfg #: MT5000-3/16-6
Manufacturer: TE Connectivity
Mfg #: MT5000-3/16-6
Manufacturer: TE Connectivity
Contact 800-633-6339 for Availability
Request Quote for Price
TE Connectivity's MT5000 3/16 inch LDPE heat shrink tubing is a medical-grade, flexible, polyolefin heat-shrinkable tubing suitable for applications requiring excellent electrical insulation performance and resistance to abrasion and harmful solvents. Blue. TE MT5000-3/16-6.
Must purchase in increments of 100.
Specifications
Download Spec Sheet| MANUFACTURER TE Connectivity | MANUFACTURER PART NUMBER MT5000-3/16-6 | SERIES MT5000 |
| HEAT SHRINK Yes | SHRINK RATIO 2:1 | WALL TYPE Single |
| MATERIAL LDPE | MEDICAL GRADE Yes | SIZE 3/16 |
| COLOR Blue | EXPANDED ID (IN) 0.187 | EXPANDED ID (MM) 4.75 |
| RECOVERED ID MAX (IN) 0.093 | RECOVERED ID MAX (MM) 2.36 | NOMINAL RECOVERED WALL THICKNESS (IN) 0.02 |
| NOMINAL RECOVERED WALL THICKNESS (MM) 0.5 | OPERATING TEMPERATURE -94°F to 221°F (-70°C to 105°C) | RECOVERY TEMPERATURE 212°F (100°C) |
| FLEXIBILITY Flexible | TRADE OR BRAND NAME RAYCHEM |
