Industrial Ethernet Protocols

As the use of ETHERNET is becoming more and more prominent, especially in industrial settings, industrial protocols are becoming normalized terms when looking for products for systems such as automation and process control. Refer to the below table to decipher which protocol may be best for your operations to abide by.

 Download Industrial Ethernet Protocols PDF

Protocol

EtherNet/IP

PROFINET

EtherCAT

POWERLINK

  Ethernet/IP Logo PROFINET Logo



EtherCAT Logo

Ethernet Powerlink
Developer Rockwell Automation Siemens Beckhoff Automation B & R Automation
Standards Body ODVA PNO/PI International EtherCAT Technology Group Ethernet Powerlink Standardization Group
Real-time Approach S/S: Standard Software/Standard Ethernet O/M: Open Software/Modified Ethernet O/M: Open Software/Modified Ethernet O/S: Open Software/Standard Ethernet
Description EtherNet/IP is a very widely supported protocol that uses standard Ethernet hardware and both TCP/IP and UDP/IP for transferring data. It has limited real-time capabilities vs some other protocols, but it's able to run servo-motor controls as well as having broad applicability to discrete-control industrial automation systems. Covers discrete/factory automation and process automation in addition to motion control. Encompasses two performance classes - PROFINET RT (real-time) or PROFINET IRT (hard real-time). EtherCAT (based on the summation frame method) and the Open Software / Modified Ethernet methodology and is capable of very fast speed with its "processing on the fly" principle where EtherCAT messages are passed before processing at each node. Ethernet Powerlink is a real-time protocol for standard ethernet, fully supporting TCP/IP. The protocol provides high performances and clear diagnostics and brings together Ethernet, CANopen and hard real-time capabilities.
CABLING TOPOLOGIES:
Tree Topology X X May be applicable X
Star Topology X X May be applicable X
Ring Topology X X X X
Daisy-chain Topology X X X X
INTERNATIONAL STANDARDS SUPPORT:
IEC 61158 Type 2 Type 10 Type 12 Type 13
IEC 61784-2 CPF 2 CPF3 CPF 12 CPF 13
GB National Chinese Standard GB/Z 26157-2010 GB/Z 25105-2010  Not applicable GB/T 27960-2011
CAPABILITIES AND PERFORMANCE:
Downward Protocol Capability X X X X
Cycle Time Performance May be applicable

RT: May be applicable

IRT: X

X X
Heavy Data Prioritization X X May be applicable X
Gigabit Readiness X

RT: May be applicable

IRT: Not applicable

Not applicable  X
EMC Susceptibility X X May be applicable X
Hot Plugging Capability X X May be applicable X
AVAILABILITY:
Ring Redundancy May be applicable May be applicable X X
Master & Cable Redundancy May be applicable May be applicable May be applicable X
