NEMA HP-3 / M16878 / Type E / UL 1213 Hook-Up Wire - 20 AWG 7 Strand - Red

Name: NEMA HP-3 / M16878 / Type E / UL 1213 Hook-Up Wire - 20 AWG 7 Strand - Red
Brand: Approved Manufacturers
SKU: KLTE20-7-2
Price: 429.2 USD
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Part #: KLTE20-7-2
Manufacturer: Approved Manufacturers

Contact 800-633-6339 for Availability

Request Quote for Price

This NEMA HP-3 (M16878) Type E Commercial & Mil Spec PTFE wire is used in internal wiring of electronic equipment and appliances. Nema HP-3 insulation is self extinguishing, non-flammable, has excellent chemical resistance and is suitable for immersion in gasoline. 20 AWG 7 strands in a red jacket. Also, available in other colors. Can be striped upon request.

Must purchase in increments of 500.

Specifications

Download Spec Sheet

MANUFACTURER Approved Manufacturers	UL STYLE / STANDARD UL 1213	TYPE NEMA HP-3 Type E
AWG/GAUGE 20	CONDUCTOR STRANDING Stranded	STRAND COUNT 7
CONDUCTOR MATERIAL Silver Plated Copper	JACKET COLOR Red	INSULATION MATERIAL PTFE
NOMINAL OD (IN) 0.058	NOMINAL OD (MM) 1.4732	TEMPERATURE 200°C
STANDARDS/APPROVALS UL Approved	MIL-SPEC M16878/4	WEIGHT LBS/MFT 5
