Alpha Xtra-Guard®1 Foil Shield Multiconductor Cable - 14 AWG 3 Conductor - Slate - 600V - 1000 ft
Alpha Xtra-Guard®1 Foil Shield Multiconductor Cable - 14 AWG 3 Conductor - Slate - 600V - 1000 ft
Part #: ALP5450/3-SL001
Mfg #: 5450/3 SL001
Manufacturer: Alpha Wire
Mfg #: 5450/3 SL001
Manufacturer: Alpha Wire
In Stock
$10,730.88 / 1,000 FT $10.73 / 1 FT
Alpha Xtra-Guard®1 is a high performing PVC control cable for general purpose applications featuring a premium-grade PVC insulation and jacket for easier routing, oil resistance and UV sun resistance. Foil Shield, Multiconductor, 600V, Slate, 1000ft, 5450/3 SL001
Must purchase in increments of 1000.
Specifications
Download Spec Sheet| MANUFACTURER Alpha Wire | MANUFACTURER PART NUMBER 5450/3 SL001 | SERIES Xtra-Guard 1 |
| AWG/GAUGE 14 | NUMBER OF CONDUCTORS 3 | CONDUCTOR MATERIAL Tinned Copper |
| CONDUCTOR STRANDING Stranded | SHIELDING Foil | JACKET COLOR Gray |
| JACKET MATERIAL PVC | NOMINAL OD (IN) 0.432 | NOMINAL OD (MM) 10.9728 |
| VOLTAGE 600V | TEMPERATURE 105°C | ATTRIBUTES Multi-Conductor |
| STANDARDS/APPROVALS VW-1 UL 1685 |
