Alpha EcoCable® Mini Foil Shield Multiconductor Cable - 26 AWG 2 Conductor - Slate - 300V - 100 ft

Name: Alpha EcoCable® Mini Foil Shield Multiconductor Cable - 26 AWG 2 Conductor - Slate - 300V - 100 ft
Brand: Alpha Wire
SKU: ALP78112-SL005
Price: 601.08 USD
Availability: InStock

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Part #: ALP78112-SL005
Mfg #: 78112 SL005
Manufacturer: Alpha Wire

Contact 800-633-6339 for Availability

$601.08 / 100 FT $6.01 / 1 FT

The Alpha EcoGen series of products are next generation eco-friendly, high performance products in a reduced diamater and weight. Constructed with mPPE insulation and jacket material these products are zero halogen and are a smaller and lighter alternative to PVC. EcoCable® Mini, Foil Shield, 300V, Multiconductor, 100ft, 78112 SL005

Must purchase in increments of 1.

Specifications

Download Spec Sheet

MANUFACTURER Alpha Wire	MANUFACTURER PART NUMBER 78112 SL005	SERIES EcoCable Mini
AWG/GAUGE 26	NUMBER OF CONDUCTORS 2	CONDUCTOR MATERIAL Tinned copper
CONDUCTOR STRANDING Stranded	SHIELDING Foil	JACKET COLOR Gray
JACKET MATERIAL mPPE	NOMINAL OD (IN) 0.106	NOMINAL OD (MM) 2.6924
VOLTAGE 300V	TEMPERATURE -40°C to +80°C	ATTRIBUTES Multi-Conductor
STANDARDS/APPROVALS CE Approved VW-1 UL AWM 21460
